Fire Prevention
Spark detection and extinguishing system
Detect hot particles before they glow
Firefly’s spark detection system uses TrueIR™ detectors and advanced signal processing to detect hot particles in the process flow, even if they are not glowing.
Sparks visible to the human eye have a temperature of at least 700°C (1292°F). But many materials, such as wood, can catch fire at much lower temperature, around 400°C (752°F). By the time sparks can be seen, it may already be too late.
Firefly TrueIR™
Spots hot particles and glowing embers that pose a risk before visible flames emerge.
Spark detector – Insensitive to daylight
The Firefly TrueDetect™ technology is insensitive to daylight and enables detection down to the minimum ignition temperature (MIT).
Firefly’s TrueIR™ detectors only operate in the infrared spectrum. Conventional spark detectors, by contrast, are based on silicone photodiodes that detect visible light and near-infrared radiation, i.e. temperatures from 650°C (1202°F) or higher.
All Firefly TrueIR™ detectors are equipped with patented Multi-Checkpoint™ technology to ensure rapid and accurate detection. Using a derivative measuring principle, Firefly detectors can identify hazardous particles traveling at speeds up to 50 meters per second.
Minimum ignition temperature and energy level
| MATERIAL | CLOUD | LAYER | MIN. CLOUD IGNITION ENERGY, J |
|---|---|---|---|
| WOOD | 470 °C / 878 °F | 260 °C / 500 °F | 0,04 |
| WHEAT FLOUR | 440 °C / 824 °F | 440 °C / 824 °F | 0,06 |
| CELLULOSE | 480 °C / 896 °F | 270 °C / 518 °F | 0,08 |
| SUGAR | 370 °C / 698 °F | 400 °C / 608 °F | 0,03 |
| COCOA | 510 °C / 950 °F | 240 °C / 464 °F | 0,10 |
| ALUMINUM | 610 °C / 1130 °F | 326 °C / 619 °F | 0,01 |
| COFFEE | 720 °C / 1328 °F | 270 °C / 518 °F | 0,16 |
Source: NFPA (National Fire Protection Association)
Download
Fire Spark Dectection System
Why Choose Firefly?
Ultra Quick System Response Time
The Quick Suppression System, which is part of our protection solution for shredders, operates with high performance flame detectors for extremely quick detection. The efficient water mist system has remarkable suppression capabilities which reduce damages on machinery.
Full – Cone Water Spray Extinguishing
Powerful extinguishing with a unique nozzle design and placement aimed to penetrate and cover the entire material flow. Activated within milliseconds after detection.
Precision Detection
The True IR Spark detectors enable Precision Detection of ALL types of ignition sources such as hot black particles, glowing embers, and sparks. The detectors are insensitive to daylight. Systems are also equipped with Multi-Channel flame detectors using advanced algorithms for Precision Detection of flames with high immunity to false positives.
Excellent Suppression Capabilities
The Water Mist System with fire-tested and verified extinguishing capabilities utilizes very small amounts of water resulting in less impact on machinery, minimized production loss and down time.
Director of Operations at Factory X
John Bennick
FNA took the time to understand our challenges and came up with customized solutions that we never considered.
FM Approved Fire Protection
All our fire prevention products are FM approved, meeting the highest safety standards. As the official North American distributor for Firefly, we provide cutting-edge protection, including the only FM-approved spark detection system for high-temperature particles.
Industries We Protect
Fire Safety Solutions for High-Risk Industries. We protect industries where fire risks are high, ensuring operational safety and business continuity.
